Drawer
Sometimes, Dialog does not always satisfy our requirements, let's say you have a massive form, or you need space to display something like terms & conditions, Drawer has almost identical API with Dialog, but it introduces different user experience.
TIP
Since v-model is natively supported for all components, visible.sync has been deprecated, use v-model="visibilityBinding" to control the visibility of the current drawer.
Basic Usage
Callout a temporary drawer, from multiple direction
You must set model-value for Drawer like Dialog does to control the visibility of Drawer itself, it's boolean type. Drawer has three parts: title & body & footer, the title is a named slot, you can also set the title through attribute named title, default to an empty string, the body part is the main area of Drawer, which contains user defined content. When opening, Drawer expand itself from the right corner to left which size is 30% of the browser window by default. You can change that default behavior by setting direction and size attribute. This show case also demonstrated how to use the before-close API, check the Attribute section for more detail
No Title
When you no longer need a title, you can remove it from the drawer.
Set the withHeader attribute to false, you can remove the title from drawer, thus your drawer can have more space on screen. If you want to be accessible, make sure to set the title attribute.
Customized Content
Like Dialog, Drawer can be used to display a multitude of diverse interactions.
Customized Header
The header slot can be used to customize the area where the title is displayed. In order to maintain accessibility, use the title attribute in addition to using this slot, or use the titleId slot property to specify which element should be read out as the drawer title.
Resizable Drawer 2.11.0
Try to drag the edge part.
Set resizable to true to resize.
Nested Drawer
You can also have multiple layer of Drawer just like Dialog.
If you need multiple Drawer in different layer, you must set the append-to-body attribute to true
Modal
Setting modal to false will hide modal (overlay) of drawer.
Starting from version 2.11.6, modal-penetrable attribute is added, which can be penetrable.
TIP
The content inside Drawer should be lazy rendered, which means that the content inside Drawer will not impact the initial render performance, therefore any DOM operation should be performed through ref or after open event emitted.
TIP
Drawer provides an API called destroy-on-close, which is a flag variable that indicates should destroy the children content inside Drawer after Drawer was closed. You can use this API when you need your mounted life cycle to be called every time the Drawer opens.
API
Attributes
| Name | Description | Type | Default |
|---|---|---|---|
| model-value / v-model | Should Drawer be displayed | boolean | false |
| append-to-body | Controls should Drawer be inserted to DocumentBody Element, nested Drawer must assign this param to true | boolean | false |
| append-to 2.8.0 | which element the Drawer appends to. Will override append-to-body | CSSSelector / HTMLElement | body |
| lock-scroll | whether scroll of body is disabled while Drawer is displayed | boolean | true |
| before-close | If set, closing procedure will be halted | Function | — |
| close-on-click-modal | whether the Drawer can be closed by clicking the mask | boolean | true |
| close-on-press-escape | Indicates whether Drawer can be closed by pressing ESC | boolean | true |
| open-delay | Time(milliseconds) before open | number | 0 |
| close-delay | Time(milliseconds) before close | number | 0 |
| destroy-on-close | Indicates whether children should be destroyed after Drawer closed | boolean | false |
| modal | Should show shadowing layer | boolean | true |
| modal-penetrable 2.11.6 | whether the mask is penetrable. The modal attribute must be false. | boolean | false |
| direction | Drawer's opening direction | enum | rtl |
| resizable 2.11.0 | enable resizable feature for Drawer | boolean | false |
| show-close | Should show close button at the top right of Drawer | boolean | true |
| size | Drawer's size, if Drawer is horizontal mode, it effects the width property, otherwise it effects the height property, when size is number type, it describes the size by unit of pixels; when size is string type, it should be used with x% notation, other wise it will be interpreted to pixel unit | number / string | 30% |
| title | Drawer's title, can also be set by named slot, detailed descriptions can be found in the slot form | string | — |
| with-header | Flag that controls the header section's existence, default to true, when withHeader set to false, both title attribute and title slot won't work | boolean | true |
| modal-class | Extra class names for shadowing layer | string | — |
| header-class 2.9.3 | custom class names for header wrapper | string | — |
| body-class 2.9.3 | custom class names for body wrapper | string | — |
| footer-class 2.9.3 | custom class names for footer wrapper | string | — |
| z-index | set z-index | number | — |
| header-aria-level a11y | header's aria-level attribute | string | 2 |
| custom-class deprecated | Extra class names for Drawer | string | — |
WARNING
custom-class has been deprecated, and will be removed in 2.3.0, please use class.
Events
| Name | Description | Type |
|---|---|---|
| open | Triggered before Drawer opening animation begins | Function |
| opened | Triggered after Drawer opening animation ended | Function |
| close | Triggered before Drawer closing animation begins | Function |
| closed | Triggered after Drawer closing animation ended | Function |
| open-auto-focus | triggers after Drawer opens and content focused | Function |
| close-auto-focus | triggers after Drawer closed and content focused | Function |
Slots
| Name | Description |
|---|---|
| default | Drawer's Content |
| header | Drawer header section; Replacing this removes the title, but does not remove the close button. |
| footer | Drawer footer Section |
| title deprecated | Works the same as the header slot. Use that instead. |
WARNING
title has been deprecated, and will be removed in 3.0.0, please use header.
Exposes
| Name | Description |
|---|---|
| handleClose | In order to close Drawer, this method will call before-close. |
